The Malcom DS-03 and DS-05 Dip Testers Measure dual
wave soldering systems. Attain vital soldering performance information with just one
device.
DS-03 Dip Tester
 |
Features and
Benefits:
- The self contained DS-03 rides along the conveyor like a
PCB.
- Measures the record's maximum PCB topside preheat
temperature.
- Confirms flux and solder levels.
- Measures and records the maximum temperature and dwell times
of both solder waves.
- Optional printer unit available.
|
Measurement Data
Specifications
| Item |
Sensor |
Measuring Range |
Accuracy/Contents |
| Soldering Temperature |
CA sheath thermocouple |
0 to 300 C |
+/- 2 C |
| Temperature on the topside of board |
CA thermocouple |
50 to 300 C |
+/- 2 C |
| Dip Time |
Electrode |
0 to 10.0 sec |
+/- 0.2 sec |
| Flux Dryness |
Electrode (resistance) |
|
|
| Flux Height |
Electrode |
0 to 6 mm |
scale resolution 1mm |
| Solder Height |
Electrode |
0 to 6 mm |
scale resolution 1mm |
* Specifications subject to change without
notice.
General Specifications
| Item |
Contents |
Cold contact point
compensation |
Automatic compensation with platinum
temperature
measuring resistor |
| Ambient temperature |
5 minutes or less OK at ambient 120 C |
| Battery |
one(1) 9V DC Battery |
| Battery life |
More than 10 continuous hours |
Life of sensor
mounting plate |
More than 5,000 times at soldering temperature
of
250 C and dip time of 5 sec |
| Dimensions |
94mm(L) X 230mm(W) X 51mm(H) |
| Weight |
840g without battery |
* Specifications subject to change without
notice.
DS-05 Dip Tester
 |
Features and
Benefits:
- Measures PCB topside, pre-heat temperature, and solder
temperature at your desired positions.
- Three(3) points dip time sensor to make dip time more
certain.
- Possible to measure conveyor speed.
|
Measurement Data
Specifications
| Item |
Sensor |
Measuring Range |
Accuracy |
| Pre-Heat Temp |
Thermocouple |
0 to 300 C |
+/- 2 C |
| Soldering Temperature |
Thermocouple |
0 to 300 C |
+/- 2 C |
| Dip time |
Electrode |
0 to 10.0 sec |
+/- 0.2 sec |
| Conveyor Speed |
Electrode |
0.1 to 9.9 m/min |
+/- 0.5 m/min |
* Specifications subject to change without
notice.
General Specifications
| Item |
Description |
| Temperature calibration |
Automatically calibrated by pre-heat sensor |
| Operating temperature |
5 minutes at 120 C or less |
| Batteries |
(4) AA batteries |
| Battery time |
Over 10 continuous hours |
| Dimensions |
84mm(L) X 180mm(W) X 38mm(H) |
| Weight |
1.3 kg (3 lbs) |
* Specifications subject to change without
notice.
|
